AGRAS T30
Unmanned Aircraft Flight Manual
Spinner Disk
Washer
Nut
Pin
Operate with caution to avoid injury caused by sharp or moving mechanical parts.
Specications
Compatible Aircraft
[1]
Agras T30
Spreading System Weight (inc. spread
tank and fenders)
4.1 kg
Spread Tank Volume 40 L
Spread Tank Internal Load
[2]
35 kg
Compatible Material Diameter 0.5-5 mm
Spreading Range
Varies according to material diameter, spinner disk
rotational speed, hopper outlet size, and ight altitude.
For optimal performance, it is recommended to adjust the
corresponding variables to achieve a spreading range of
5-7 meters.
[1] The aircraft rmware must support the spreading system. Check the release notes of the corresponding aircraft on the ofcial
DJI website.
[2] The DJI Agras app will intelligently recommend the payload weight limit for the spread tank according to the current status
and surroundings of the aircraft. Do not exceed the recommended payload weight limit when adding material to the spread
tank. Otherwise, the ight safety may be affected.
Maintenance
1. Clean the residue in the spread tank and spreader immediately after spreading and keep the system
dry.
2. The spinner disk is a consumable part. Follow the steps below to replace the spinner disk if there are
obvious signs of wear.
a. Make sure that the aircraft is powered off.
b. Remove the pin, nut, washer, and spinner disk at the bottom of the spreader. Mount a new
spinner disk and secure it using the washer, nut, and pin.
