dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
25
©
2022 DJI All Rights Reserved.
in the illustration below, the aircraft can only take off and land away from the Restricted
or Authorization Zone when inside the buffer zone. The aircraft cannot fly toward the
Restricted or Authorization Zone unless an unlocking request has been approved. The
aircraft cannot fly back into the buffer zone after leaving the buffer zone.
Buffer Zones for Altitude Zones: a buffer zone of about 20 meters wide is established
outside each Altitude Zone. As shown in the illustration below, when approaching the
buffer zone of an Altitude Zone in a horizontal direction, the aircraft will gradually reduce
its flight speed and hover outside the buffer zone. When approaching the buffer zone from
underneath in a vertical direction, the aircraft can ascend and descend in altitude or fly
away from the Altitude Zone. The aircraft cannot fly toward the Altitude Zone. The aircraft
cannot fly back into the buffer zone in a horizontal direction after leaving the buffer zone.
Unlocking GEO Zones
To satisfy the needs of different users, DJI provides two unlocking modes: Self-Unlocking and
Custom Unlocking. Users may request either on the DJI Fly Safe website or via a mobile device.
Self-Unlocking is intended for unlocking Authorization Zones. To complete Self-Unlocking, the
user must submit an unlocking request via the DJI Fly Safe website at https://www.dji.com/
flysafe. Once the unlocking request is approved, the user may synchronize the unlocking license
through the DJI Pilot 2 app (Live Self-Unlocking). To unlock the zone, alternatively, the user may
launch or fly the aircraft directly into the approved Authorization Zone and follow the prompts
in DJI Pilot 2 to unlock the zone (Scheduled Self-Unlocking). For Live Self-Unlocking, the user can
designate an unlocked period during which multiple flights can be operated. Scheduled Self-
Unlocking is only valid for one flight. If the aircraft is restarted, the user will need to unlock the
zone again.
Ground
Restricted Zone/
Authorized Zone
Ground
Buffer Zone
Altitude Zone
Altitude Limit
20 m
20 m
20 m
20 m

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
