dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
40
©
2022 DJI All Rights Reserved.
• DO NOT charge an Intelligent Flight Battery immediately after flight as it may be too
hot. Wait for the battery to cool down to the operating temperature before charging
again.
• The charger stops charging the battery if the battery cell temperature is not within the
operating range of 5° to 40° C (41° to 104° F). The ideal charging temperature is from
22° to 28° C (71.6° to 82.4° F).
• Fully charge the battery at least once every three months to maintain battery health.
• DJI does not take any responsibility for damage caused by third-party chargers.
For safety purposes, keep the batteries at a low power level in transit. This can be done by
flying the aircraft outdoors until there is less than 30% charge left.
The table below shows the battery level during charging.
LED1 LED2 LED3 LED4 Battery Level
1%-50%
51%-75%
76%-99%
100%
Battery Protection Mechanisms
The battery level LEDs can display battery protection notifications triggered by abnormal
charging conditions.
Battery Protection Mechanisms
LED1 LED2 LED3 LED4 Blinking Pattern Status
LED2 blinks twice per second Overcurrent detected
LED2 blinks three times per second Short circuit detected
LED3 blinks twice per second Overcharge detected
LED3 blinks three times per second
Over-voltage charger
detected
LED4 blinks twice per second
Charging temperature is
too low
LED4 blinks three times per second
Charging temperature is
too high

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
