dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
41
©
2022 DJI All Rights Reserved.
If any of the battery protection mechanisms are activated, unplug the charger, and plug it
in again to resume charging. If the charging temperature is abnormal, wait for it to return
to normal. The battery will automatically resume charging without the need to unplug and
plug the charger again.
Inserting the Intelligent Flight Battery
Insert the Intelligent Flight Battery into the battery compartment of the aircraft. Make sure
it is mounted securely and that the battery buckles are clicked into place.
Click
Removing the Intelligent Flight Battery
Press the textured part of the battery buckles on the sides of the battery to remove it from
the compartment.
2
1
• DO NOT insert or remove the battery while the aircraft is powered on.
• Make sure the battery is mounted securely.

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
