dji MAVIC 3T User Manual

DJI Mavic 3E/3T User Manual
82
©
2022 DJI All Rights Reserved.
Backward Measurement Range: 0.5-16 m
Effective Sensing Speed: Flight Speed ≤12 m/s
FOV: Horizontal 90°, Vertical 103°
Lateral Measurement Range: 0.5-25 m
Effective Sensing Speed: Flight Speed ≤15 m/s
FOV: Horizontal 90°, Vertical 85°
Upward Measurement Range: 0.2-10 m
Effective Sensing Speed: Flight Speed ≤6 m/s
FOV: Front and Back 100°, Left and Right 90°
Downward Measurement Range: 0.3-18 m
Effective Sensing Speed: Flight Speed ≤6 m/s
FOV: Front and Back 130°, Left and Right 160°
Operating Environment Forward, Backward, Lateral, and Upward: surface with a clear
pattern and adequate lighting (lux >15)
Downward: diffuse reflective surface with diffuse reflectivity>20%
(e.g. walls, trees, people) and adequate lighting (lux >15)
Video Transmission
Video Transmission
System
DJI O3 Enterprise Transmission
Live View Quality Remote Controller: 1080p/30fps
Operating Frequency
[2]
2.400-2.4835 GHz, 5.725-5.850 GHz
Transmitter Power (EIRP) 2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <14 dBm (CE), <30 dBm (SRRC)
Max Transmission
Distance (unobstructed,
free of interference)
[3]
15 km (FCC), 8 km (CE/SRRC/MIC)
Max Transmission
Distance (Obstructed)
[4]
Strong Interference (dense buildings, residential areas, etc.):
1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban areas, city parks, etc.):
3-9 km (FCC), 3-6 km (CE/SRRC/MIC)
Low Interference (open spaces, remote areas, etc.):
9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
Max Download Speed
[5]
15 MB/s (with DJI RC Pro Enterprise)
Latency (depending
on environmental
conditions and mobile
device)
Approx. 200 ms
Antenna 4 Antennas, 2T4R
Remote Controller
Screen Resolution 1920×1080
Screen Size 5.5 inch
Screen Frame Rate 60fps
Screen Brightness 1000 nit
Touchscreen Control 10-point multi-touch
Battery Li-ion (5000 mAh @ 7.2 V)

dji MAVIC 3T Specifications

General

Built-in processor	-
Internal memory	64 GB
Memory card slot(s)	Yes
Compatible memory cards	MicroSD (TransFlash)
AC adapter power	100 W
AC adapter frequency	50/60 Hz
AC adapter input voltage	100/240 V
AC adapter output current	2.5 A
Operating temperature (T-T)	-10 - 40 °C
Moving control functions	Backward, Downward, Forward, Upward
Megapixel	20 MP
Sensor type	CMOS
Video resolutions	1920 x 1080, 3840 x 2160, 4096 x 2160 pixels
Optical sensor size	1/2 \
Camera shutter speed	8-1/8000 s
Video formats supported	AVC, H.264, H.265, HEVC, MPEG4
Maximum image resolution	5280 x 3956 pixels
Field of view (FOV) angle	85 °
Supported video streaming modes	1080p
Battery voltage	7.2 V
Battery capacity	5000 mAh
Type	Quadcopter
Product color	Gray
USB ports quantity	1
Maximum speed	6 m/s
Frequency band	2.4 - 2.4835 GHz
Number of rotors	4 rotors
Maximum tilt angle	35 °
Hovering time (max)	45 min
Maximum ascent speed	1 m/s
Maximum weight capacity	- kg
Maximum wind resistance	12 m/s
Maximum operating distance	32000 m
Maximum yaw angular velocity	200 °/sec
