dji Ronin-MX User Manual

©
2016 DJI All Rights Reserved.
45
Specications
General
Built-In Functions
Operation Modes
Underslung Mode
Upright Mode
Briefcase Mode
Aerial Mode
Jib or Wirecam Mode
Built-in, independent IMU module
DJI Specialized Gimbal Drive
Motors with Encoders
Bluetooth Module
USB Connection
2.4 GHz Receiver
Temperature Sensor
DJI Advanced 32-Bit
DSP Processor
D-Bus Receiver
Supported
Peripheral
Camera Tray Dimensions Maximum depth from the center of gravity on camera
base plate: 120 mm.
Maximum height measured from top of the camera base
plate: 130 mm.
Maximum width: 160 mm
Accessory Power
Connections
12V Regulated P-Tap x 2
USB 500 mW x 1
DJI Lightbridge x 1
GCU Input Power Intelligent Battery: 423496-1580 mAh-14.4 V
Connections 2.4 GHz Remote Controller
Bluetooth 4.0
USB 2.0
PC/MAC Assistant
Requirements
Windows XP or above
Mac OS X 10.9 or above
Mobile Assistant Software
Requirements
iOS 7.1 or above
Android 4.3 or above
Mechanical & Electrical Characteristics
Working Current
Static current: 300 mA (@16 V)
Dynamic current: 600 mA (@16 V)
Locked motor current: Max 10 A (@16 V)
Operating Temperature 5° to 122° F (-15° to 50° C)
Weight Including handle bar: 6.11 lb (2.77 kg)
Including vibration absorber: 4.74 lb (2.15 kg)
Dimensions Excluding handle bar:
280 mm (W) x 370 mm (D)x 340 mm (H)
Including handle bar:
560 mm (W) x 370 mm (D) x 440 mm (H)

dji Ronin-MX Specifications

General

Bluetooth	Yes
Type	Hand camera stabilizer
Material	Magnesium
Motorized	-
Pan range	0 - 360 °
Product color	Black
Number of axis	3
Tilt angle range	-150 - 270 °
Angle of rotation	360 °
Compatible products	ARRI ALEXA MINI, RED DRAGON, CANON 5D, Blackmagic Design Production Camera
Maximum weight capacity	4.5 kg

Weight and Dimensions

Depth	370 mm
Width	560 mm
Height	440 mm
Weight	2770 g
