Digital Monitoring Products XTLplus Installation and Programming Guide
18
NETWORK OPTIONS
23.2.1 WPS
When WPS is selected, SEARCHING displays. Press the WPS button on the Wi-Fi
network router to which you are attempting to connect. SEARCHING displays for up
to two minutes or until connected to the WPS enabled router. Refer to the router’s
instruction manual for sending a security key to the XTLplus Series panel.
If the panel fails to connect to the WPS enabled router, WPS FAILED RETRY? NO
YES displays. Press the fourth select area to RETRY or press the third select area to
display WPS LIST MANUAL.
23.2.2 List
When LIST is selected, SEARCHING displays until any Wi-Fi networks are found
in range. Once available Wi-Fi networks are found the keypad displays the name
of the SSID (Wi-Fi Network name) and signal strength of each network. Press
COMMAND to scroll through the list of available Wi-Fi networks. When the desired
network is displayed, press any select area to connect.
Note: If the panel is unable to detect the security type, W/L SECURITY with the
default security type WPA-PSK displays. If a dierent security type is required,
press COMMAND and WEP WPA NONE displays. Press the select area of the desired
security type to choose.
When connecting to the Wi-Fi network the panel also detects the security type in
use and W/L KEY: *************** displays.
Enter the W/L KEY and the panel performs a connection test and CONNECTING
displays. When successful, CONNECTED displays on the keypad. If the panel does
not connect to the Wi-Fi network, NOT CONNECTED displays. Press COMMAND to
return to the WIFI SETUP main screen.
23.2.3 Manual
This option allows you to enter the desired network name using the keypad. When
MANUAL is selected, the current settings display. Press COMMAND to continue with
no change. SecureCom is the default.
Use the number keys on the keypad to enter a new or dierent SSID (Wi-Fi
Network name), there is no need to press a select areas. Once the SSID is entered,
press COMMAND and SEARCHING displays.
When an SSID is entered for the rst time or changed, the panel searches for the
SSID entered to ensure communication. The keypad displays SSID FOUND or SSID
NOT FOUND. When the SSID is found, the security type is also detected.
Note: Depending on the security type, the SSID might take several seconds to
process.
Enter up to 32 characters for the SSID from the network router to identify the
network LAN. The SSID is blank by default. Use the chart below to enter lowercase
or special characters. Each successive press of the select key or area gives
additional options. For example, to enter Me5%, you would press 5, select key or
area 1 (M); press 2, select key or area 2 twice (e); press 5 (5); press 7, select key
or area 4 twice (%).
Number Select Key or
Area 1
Select Key or
Area 2
Select Key or
Area 3
Select Key or
Area 4
Note:
When \ is
entered,
the keypad
displays ¥.
When ~ is
entered, ->
displays.
1 A, a, B, b C, c (, [, {
2 D, d E, e F, f ), ], }
3 G,g H,h I, i !, ^, ~
4 J, j K, k L,l ?, ", |
5 M, m N, n O,o /, \, `
6 P, p
Q, q
R, r &, $
7 S, s T, t U,u @, %
8 V, v W, w X, x , =
9 Y, y Z, z space,: _, ;
0 -, + ., ' *, < #, >
While searching, SEARCHING displays on the keypad. If the panel can not connect
to the desired network SSID NOT FOUND displays. Press COMMAND to return to the
main menu and WPS LIST MANUAL displays. Press COMMAND again to display TEST.
SEARCHING .
WPSLISTMANUAL
SEARCHING
SIGNAL ▐▐▐▐▐▐▐
HOMENET123
W/LSECURITY:
WPA-PSK
W/LSECURITY:
WEPWPANONE
W/LKEY:
*****************
W/LKEY:
-
WIFISETUP
ENTER SSID
WPSLISTMANUAL
SSID:
SSIDFOUND 
SSID:
SSIDNOTFOUND 
