Digital Monitoring Products XTLplus Installation and Programming Guide
30
ZONE INFORMATION
Zone Information
33.1 Zone Information
This allows you to dene the operation of each protection zone used in the system.
33.2 Zone Number
Zone numbers on the XTLplus panel default to the following settings. The settings
can be changed as described in the following sections. Zones 51-54 can be wireless
zones, key fobs or slow outputs. Zones 61-64 can be wireless zones, key fobs, or
fast outputs.
Zone Number Zone Name Zone Type Area Assignment
1 FRONT DOOR EX PERIM
2 BACK DOOR EX PERIM
3 GARAGE ENTRY DR NT INT
4 PATIO DOOR EX PERIM
5 BASEMENT DOOR EX PERIM
6 GARAGE DOOR EX PERIM
7 WAREHOUSE DOOR EX PERIM
8 SHIPPING DOOR EX PERIM
9 BREAKROOM DOOR NT INT
10 STOCKROOM DOOR NT INT
11 FRONT MOTION NT INT
12 BACK MOTION NT INT
13 HALLWAY MOTION NT INT
14 UPSTAIRS MOTION NT INT
15 BASEMENT MOTION NT INT
16 GARAGE MOTION NT INT
17 GLASSBREAK NT INT
18 WATER DETECTOR SV INT
19 LOW TEMPERATURE SV INT
20 SMOKE DETECTOR FI PERIM
21 FRONT SMOKE FI PERIM
22 BACK SMOKE FI PERIM
23 HALLWAY SMOKE FI PERIM
24 UPSTAIRS SMOKE FI PERIM
25 BASEMENT SMOKE FI PERIM
26 OFFICE SMOKE FI PERIM
27 WAREHOUSE SMOKE FI PERIM
28 SHIPPING SMOKE FI PERIM
29 STORAGE SMOKE FI PERIM
30 SHED DOOR EX PERIM
31 SHOP DOOR EX PERIM
32 OFFICE DOOR NT PERIM
33 BREEZEWAY DOOR NT PERIM
34 SHOP WINDOW NT PERIM
35 OFFICE WINDOW NT PERIM
36 BREEZEWAY WINDOW NT PERIM
37 BASEMENT WINDOW NT PERIM
38 SHED MOTION NT PERIM
39 SHOP MOTION NT PERIM
40 OFFICE MOTION NT PERIM
41 BREEZEWAY MOTION NT PERIM
42 DRIVEWAY BEAM NT PERIM
43 CASHIER PANIC PN PERIM
44 OFFICE PANIC PN PERIM
45 CO DETECTOR FI PERIM
46 EMERGENCY PENDNT PN PERIM
47 GARAGE HEAT AUX 1 PERIM
48 UTILITY ROOM HT AUX 1 PERIM
51 OUTPUT 1 PERIM
52 OUTPUT 2 PERIM
53 OUTPUT 3 PERIM
ZONEINFORMATION
ZONENO:-
