Digital Monitoring Products XTLplus Installation and Programming Guide
32
ZONE INFORMATION
33.7 Area Assignment
To change the default area, press any select area.
For Area systems, enter the area number from 1 to 6 where this zone is
being assigned.
For All/Perimeter systems, choose INTERIOR or PERIMETER.
For Home/Away systems, choose INTERIOR, PERIMETER, or BEDROOMS.
• INT (Interior) - Assigns the zone to area 2, Interior.
• BDRM (Bedroom)- Assigns the zone to area 3, Bedrooms. This option is only
displayed in Home/Away systems.
• PERIM (Perimeter) - Assigns the zone to area 1, Perimeter.
33.7.1 Style
This option species the style for the arming/disarming operation. The default for
STYLE: is TGL (toggle). Pressing any select area displays the STYLE options. To view
more style options press the command key. The following is a description of the
action for each option condition.
TGL (Toggle) - When the zone changes from normal to shorted, the programmed
areas toggle between the armed or disarmed condition. When restored to normal,
no action occurs. When the zone is opened from a normal (disarmed) state, a
trouble is reported. When opened from a shorted (armed) state, an alarm is
reported and the zone is disabled until you disarm the area(s) from either a keypad
or Remote Link™ computer.
ARM - When the zone is shorted, the programmed areas are armed. When restored
to normal, no action occurs. When the zone is opened from a normal (disarmed)
state, a trouble is reported. When opened from a shorted (armed) state, an
alarm is reported.
DIS (Disarm) - When programmed as an Area system, a short will disarm the
programmed areas. When programmed as a ALL/PERIM or HOME/AWAY system, a
short will disarm ALL areas. When restored to normal, no action occurs. When the
zone is opened from a normal (disarmed) state, a trouble is reported.
STEP - When programmed as an area system, a short will arm the areas and beep
the keypads once. When programmed as ALL/PERIM or HOME/AWAY, on the rst
short HOME will arm and beep the keypad once. On the second short, SLEEP will
arm and beep the keypads twice. On the third short, AWAY will arm and beep the
keypad three times. A normal condition will cause no action. An open condition will
disarm the programmed areas and beep the keypads for one second.
Note: This arming style is designed for wireless arming pendants. When using a
arming/disarming keyswitch, locate the keyswitch within the protected area.
MNT (Maintain) - When the zone is shorted, the programmed areas are armed.
When restored to normal, the programmed areas are disarmed and any alarm bells
are silenced. When the zone is opened from a normal (disarmed) state, a trouble
is reported. If opened from a shorted (armed) state, an alarm is reported and the
zone is disabled until you disarm the area(s) from either a keypad or Remote
Link™ computer.
33.8 DMP Wireless
For wireless key fob programming see the 1144 Series Key Fob section.
Note: All wireless programming is stored in the XTLplus panel. Each time the panel powers up, when the
programmer STOP routine is selected or the panel is reset, the wireless receiver memory refresh could
take up to 45 seconds to complete depending on the number of wireless zones programmed and the
Red LED remains on during this time. Normal wireless receiver operation is inhibited during the memory
refresh period.
33.8.1 Serial Number Entry
Enter the eight digit serial number, including leading zeros, found on the
wireless device.
33.8.2 Contact
This option displays if the serial number entered is for an 1101, 1103, or 1106
Universal Transmitter or 1114 Wireless Four-Zone Expander. Press any top row key
to select the contact.
This option displays when programming an 1101, 1103, or 1106 Universal
Transmitter. Select INT to use the internal reed switch contacts. Select EXT to
connect an external device to the 1101, 1103, or 1106 terminal block. Default is
INTERNAL.
By allowing both of the transmitter contacts (INT and EXT) to be used at the same
time, two zones may be programmed from one transmitter. When using multiple
contacts, you must use consecutive zone numbers.
INT PERIM
AREA:-
INT BDRM PERIM
STYLE:TOGGLE
TGL ARM DIS STEP
MNT
SERIAL#:-
INT EXT
