XTLplus Installation and Programming Guide Digital Monitoring Products
31
ZONE INFORMATION
54 OUTPUT 4 PERIM
61 ALARM SOUNDER 1 PERIM
62 ALARM SOUNDER 2 PERIM
63 ALARM SOUNDER 3 PERIM
64 ARM/ALARM/LIGHT PERIM
33.3 Key Fob
Select YES to program an 1144 Series Key Fob for zones 51-54 or 61-64.
When YES is selected, programming continues at the 1144 Series Key Fobs Section.
Default is NO.
33.4 Zone Name
Press any select area to display the default zone name. To change the default zone
name, press any select area to clear name. Enter up to 16 characters for the new
zone name. This name is displayed at the keypads when the zone is bad or viewed
in Display Events. The zone name is also sent to the receiver as part of a zone
event report.
A zone that is not part of the system must be marked *UNUSED*. To mark a zone
unused, de lete the old name by pressing any select area, then press the COMMAND
key. The pro grammer auto matically pro grams the name as * UNUSED *. If you
selected ZONES? NO YES to clear the panel’s memory during Initialization, the
zones will already be marked * UNUSED *. See the Initialization section.
33.5 Zone Type
The Zone Type denes the panel’s response to the zone being opened or shorted.
Refer to the Appendix for zone type defaults and descriptions.
Each zone has a default type. When you assign a Zone Type to a zone, responses
are made automatically for the zone. There are 11 Zone Types to choose from
including Blank. The func tional details of each response are described in Zone Type
Defaults in the Appendix.
To change the Zone Type, press any select area. The display lists the four Zone
Types shown below. When the Zone Type you want to select displays, press the
select area below the name.
Blank, Night, Day, or Exit. Press COMMAND to display additional zone types.
Fire, Panic, Emergency, or Supervisory. Press COMMAND to display additional zone
types.
Auxiliary 1, Auxiliary 2, Fire Verify, or Arming. Press the Back Arrow key to display
the previous zone types.
If you select Blank, Night, Day, Exit, Auxiliary 1, or Auxiliary 2 as the Zone Type,
the zone must be assigned to an area. If you select Fire, Panic, Emergency, or
Supervisory as the Zone Type, these are 24-hour zones that are always armed and
no area assignment is needed. Press COMMAND to continue.
Refer to the Appendix for zone type specications and descriptions.
33.6 Arming Zone Assignment
For Area systems, this option species the areas to be armed by the Arming Type
zone. Press the appropriate number keys on the keypad to assign areas 1 to 6.
When disarmed, all programmed areas are disarmed.
For All/Perimeter systems, choose PERIM or ALL. For Home/Away systems, choose
HOME, SLEEP, or AWAY.
Perimeter/All - Specify whether the arming zone arms just the Perimeter (PERIM)
or the Perimeter and Interior areas (ALL) for All/Perimeter systems. When
disarming, all areas are disarmed.
HOME/SLEEP/AWAY - Specify whether the arming zone arms the Perimeter (HOME),
the Perimeter and Interior (SLEEP), or all three areas (AWAY). When disarming, all
areas are disarmed.
Arming zone operation
If a bad (faulted) Priority zone is in the area being armed by an Arming zone,
the arming is stopped. If there are no Priority zones, or they are all in a normal
condition, the following applies:
When a non-Priority zone is bad when an area is armed with a keyswitch on an
Arming zone, the arming is delayed for ve seconds. If, during the ve-second
delay, the keyswitch is turned to disarm, the arming stops. If the keyswitch is held
in the arming position for the full ve seconds, the bad zone is force armed and
the area is armed.
The ability to stop the arming does not apply if a wireless arming device is being
used. Refer to the Appendix.
Note: Arming from a zone, Wi-Fi, or Remote Link is not aected by this operation.
KEYFOB NO YES
*UNUSED*
ZONETYPE:-
FI PN EM SV
A1 A2 FV AR
-- NT DY EX
AREA:
ARMAREA:  PERIM
PERIM  ALL
HOMESLEEP AWAY
