OUTPUT OPTIONS
Output Options
30.1 Output Options
This section allows you to program output options for the 1116 and 1117 wireless
outputs. Select from the following output numbers:
• 51 to 54
• 61 to 64
• F01 to F20 (To Activate Z-Wave Favorites)
30.2 Communication Failure Output
This output/Favorite turns on when the panel fails to communicate with the
receiver after three communication attempts. Enter 0 (zero) to disable this output.
Note: To turn o the Communication Failure Output, disarm the panel or turn the
output o using the User Menu Outputs On/O function.
30.3 Fire Alarm Output
This output turns on any time a re type zone is placed in alarm. The output turns
o using the Sensor Reset option when no additional re type zones are in alarm.
Enter 0 (zero) to disable this output.
30.4 Fire Trouble Output
This output/Favorite turns on any time a re type zone is placed in trouble or
when a supervisory type zone is placed in alarm or trouble. The output turns
o when all re and supervisory type zones restore to normal. Enter 0 (zero)
to disable.
30.5 Ambush Output
This output/Favorite turns on any time an Ambush code is entered at a keypad.
The output turns o using the Sensor Reset option. Enter 0 (zero) to disable
this output.
30.6 Begin Exit Output
This output/Favorite turns on any time an exit delay time starts. The output turns
o when the system arms or when the arming has been stopped. Enter 0 (zero)
to disable.
30.7 End Exit Output
This output/Favorite turns on any time an exit delay time ends. The output turns
o when the system disarms. Enter 0 (zero) to disable.
30.8 Ready Output
This output/Favorite turns on whenever all disarmed zones are in a normal state.
The output turns o when any disarmed zone is in a bad state. Enter 0 (zero)
to disable.
30.9 Armed Output
The entered output turns on any time the system is armed. The keypad display is
dependent on the system’s arming type.
For Home/Away systems, only the HOME and AWAY screens display. If a Bedroom
area is programmed into the panel, the SLEEP screen also displays. For All/
Perimeter systems, the ALL and PERIM screens display. For Area systems, the OUT
screen displays.
All options are defaulted to 0 (zero). The output turns o when the system
completely disarms. Enter 0 (zero) to disable this output.
30.10 Disarmed Output
This output/Favorite turns on when all areas of the panel are disarmed. The output
turns o when an area is armed.
30.11 Burglary Output
This output/Favorite turns on any time a burglary zone goes into alarm. The output
turns o when the area in which the alarm occurred disarms and no other burglary
zones are in alarm. Enter 0 (zero) to disable this output.
30.12 Arm-Alarm Output
Enter the output/Favorite to turn on steady when any area of the system is
armed. If an alarm occurs causing the keypads to turn Red, this output pulses and
continues to pulse for approximately three (3) minutes after the panel is disarmed.
Enter 0 (zero) to disable.
OUTPUTOPTIONS
COMFAILOUT: 0
FIREALROUT: 0
FIRETRBOUT: 0
AMBUSH OUT: 0
BEGINEXIT:0
ENDEXIT:0
READY OUT: 0
ARMED OUT: 0
ARMED PERIM: 0
ARMED AWAY: 0
ARMED SLEEP: 0
ARMED HOME: 0
ARMED ALL: 0
DISARMEDOUT: 0
BURGLARYOUT: 0
ARM-ALARMOUT: 0
