XTLplus Installation and Programming Guide Digital Monitoring Products
41
APPENDIX
To begin the cellular activation for a 265C CDMA Cellular Communicator, verify that the 265C MEID has been
added for the panel using Remote Link or by calling Customer Service (1-800-641-4282). At the keypad, press
any select area when ACTIVATE CELL is displayed on the keypad. When the SURE NO YES? conrmation
menu appears press the select area beneath YES to complete the cellular activation.
Successful Display Failure Display
CELL ACTIVATED NOT ACTIVATED
Wi-Fi Signal Strength (Wi-Fi SIGNAL)
This option tests the signal strength of the selected SSID. Press any select area to
display Wi-Fi signal strength. The
▐
’s represent the signal strength 0-7.
Wi-Fi Signal Strength
Number of Bars Indication
7
Good Signal (Excellent for consistent operation)6
5
4
Average Signal (Expect consistent operation)3
2
1 Weak Signal (Will not operate reliably. Relocate Wi-Fi
equipment or add a Wi-Fi extender for better reception.)
0 No Signal
Z-Wave Test Option
This feature allows the installer to test XTLplus communication with Z-Wave
devices. A successful test indicates a response from a device. Press any select area
to view the Z-Wave Device List.
Press COMMAND to advance through each Z-Wave device and press any select area
to begin the test on the device displayed.
The name of the device displays above the device number. The current number of
successful communications followed by the total number of attempts displays to
the right of the device number. The test stops after 99 attempts.
Press COMMAND to view the nal number of successful communications.
Exiting the Diagnostics program
Press the COMMAND key until STOP displays. Press any select area. The keypad returns to the Status
List display.
36.5 Using the Walk Test
The XTLplus panel provides a walk test feature that allows a single technician to test all the protection
devices connected to zones on the system. Conduct the Walk Test within 30 minutes of resetting the panel.
The Walk Test automatically ends if no zones are tripped for 20 minutes. TEST IN PROGRESS displays at all
keypads. When ve minutes remain, TEST END WARNING displays. If any areas are armed the Walk Test does
not start and SYSTEM ARMED displays.
Walk Test
To conduct the Walk Test, reset the control panel by pressing the RESET button
then wait one minute. From the keypad, enter the code 8144. The keypad displays
WALK TEST.
WLS (Wireless Check-in Test) - Select WLS to automatically test 1100 Series
wireless transmitter communications. Includes all wireless devices except key fobs
and transmitters programmed for a supervision time of 0 (zero).
PIR (Wireless PIR Walk Test) - The PIR Walk Test allows the installer to verify the
1126 and 1127 operation. When enabled, the 1126 LED ashes each time motion is
detected for up to 30 minutes. This is a local test only and no messages are sent to
the Central Station.
Trip Counter For DMP Wireless Check-in Test (WLS)
Displays the number of wireless zones that automatically communicate a
supervisory check-in message.
• The number of zones that check in. (XXX in the example).
SIGNAL ▐▐▐▐▐▐▐
HOMENET123
TEST ZWAVE
DEVICELIST:
HALLWAYLIGHT
HALLWAYLIGHT
LIGHT020/0
HALLWAYLIGHT
99/99SUCCESSFUL
WALKTEST
STDWLSPIR
WALKTEST
TRIPS:XXX  END
