ZONE INFORMATION
User Number can be added at the User Menu later by the User.
The following programming continues from when Key Fob YES is selected.
33.9.1 Key Fob User Number
Enter the User Number used to identify the key fob user and their arming and
disarming authority. Default is blank.
— User number range: 1 to 99
Displays when the User Number entered does not exist in User Code programming.
The key fob can be added, but the user must eventually be added to cause the key
fob to operate.
33.9.2 Key Fob Serial Number
Enter the eight-digit serial number found on the wireless device.
Displays when the serial number is already programmed. The programmed zone
number displays.
33.9.3 Key Fob Supervision Time
Press any top row key to select the supervision time required for the key fob zone.
Press COMMAND to accept the default time. Default is 0.
Press the select area under the required number of minutes. The key fob must
check in at least once during this time or a missing condition is indicated for that
zone. 1144 Series key fobs automatically checkin based on the supervision time
selected for the wireless zone, no additional programming is needed. Zero (0)
indicates an unsupervised transmitter.
Note: When the panel is reset the supervision timer restarts for all wireless zones.
33.9.4 Number of Key Fob Buttons
Enter the number of buttons (1, 2, or 4) on the key fob being programmed. Default
is four buttons.
Note: If the key fob is a one-button model, programming continues at the Button
Action section. Default button assignment for one-button key fobs is a Panic Alarm
(PN) with no output assigned.
33.9.5 Key Fob Button Selection (Four Buttons)
This option only displays if the key fob being programmed is a four-button model.
Press the select key under the key fob button to program. The following list
identies the default button assignments:
TOP Arming with areas 1, 2, and 3 assigned
BTM Disarming with areas 1, 2, and 3 assigned
LFT Panic Alarm (PN) with no output assigned
RGT Arming with Area 1 assigned
33.9.6 Key Fob Button Selection (Two Buttons)
This option only displays if the key fob being programmed is a two-button model.
Press the select area under the key fob button to program. The following list
identies the default button assignments:
TOP Arming with areas 1, 2, and 3 assigned
BTM Disarming with areas 1, 2, and 3 assigned
33.9.7 Button Action
This option species the Button Action for an individual key fob button. The
default action for the button selected is displayed. Press any select area to display
the Button Action options. To view more options press the COMMAND key.
ARM (Arm) - Arms selected areas and force arms bad zones.
DIS (Disarm) - Disarms selected areas.
TGL (Toggle Arm) - Toggles arm/disarm for selected areas and force arms bad
zones when arming.
STA (Status) - Causes the key fob LED to indicate the arm/disarm status of the
system.
PN (Panic) - Triggers a Panic zone type alarm with no restoral.
PN2 (Panic 2) - Triggers a Panic zone type alarm with no restoral when pressed
simultaneously with any other Panic 2 button. No action occurs when pressed
alone.
EM (Emerg) - Triggers an Emergency zone type alarm with no restoral.
KFUSERNO:
NOTINUSE
SERIAL#:-
ALREADYUSED Zxx
SUPRVSNTIME: 0
0 60 240
BUTTONS:4
TOPBTMLFTRGT
TOP BTM
ACTION:XXXXXXX
ARM DIS TGL STA
PN PN2 EM EM2
