XTLplus Installation and Programming Guide Digital Monitoring Products
29
OUTPUT SETUP
Note: When the panel is reset, a receiver is installed or powered down and
powered up, or programming is complete, the supervision timer restarts for all
wireless outputs.
31.6 Trip with Panel Bell Option
This option displays when the wireless device is an 1135 wireless siren. Select YES
to have the 1135 wireless siren follow the panel bell output. Default is YES.
Area Information
32.1 Area Information
This section allows you to assign functions to individual areas for XTLplus panels.
All non-24-hour zones must be assigned to an active area. See the section on
Zone Information.
Activate an area by assigning it a name. A name is given to each active area to
assist the user during arming and disarming.
32.2 Area Number
Enter the number of the area to program. In an area system, select from
areas 1 to 6.
In an All/Perimeter system, select INTerior or PERIMeter.
In a Home/Away system, select INTerior, BDRM, or PERIMeter.
32.3 Area Name
In an area system, enter up to 16 characters for the area name. Only those areas
given names can have zones assigned to them. All others are marked *UNUSED*.
To add an area name to the system, press any select area and then enter up to 16
characters for the new name. Refer to the Entering Alpha Characters section. Press
COMMAND to continue.
To mark an active area as unused, delete the old name by pressing any select area
then press the COMMAND key. The panel automatically sets the name as *UNUSED*.
If you have already Initialized the panel, all areas will be marked as *UNUSED*. See
section 2.3.
32.4 Automatic Arming
Select YES to allow this area to arm automatically according to the opening and
closing schedule.
If Closing Check is selected as YES, the automatic arming does not take place
until the expiration of a 10-minute Closing Check delay. If the area has been
disarmed outside a schedule, the Closing Check delay occurs one hour after the
area is disarmed.
At arming, faulted zones are handled according to the option selected in Bad
Zones. If a Closing report is sent, the user number is indicated as SCH on the SCS-
1R Receiver. Select NO to disable automatic arming for this area. Default is NO.
32.4.1 Bad Zones
At the time of automatic arming, some zones in the area may not be in a normal
condition. This option allows you to program the panel’s response to these bad
zones. This option is not displayed if AUTO ARM is NO.
BYP - All bad zones are bypassed. A report of the bypass is sent to the receiver
if Bypass Reports has been selected as YES. See the Bypass Reports section. The
report indicates SCH as the user number.
FORC - All bad zones are force armed. Zones force armed in a bad condition are
capable of restoring into the system and reporting alarms if tripped. A report of
the force arm is sent if Bypass Reports is YES. See the Bypass Reports section. The
report indicates the user number as SCH.
REF - The automatic arming is refused and no arming takes place. A No Closing
report is sent to the receiver regardless of the Closing Check selection.
Note: For listed installations, set Bad Zones to REF.
32.5 Automatic Disarming
NO disables automatic disarming by schedule for this area. Select YES to allow this
area to automatically disarm according to a schedule. If an Opening report is sent
to the receiver, the user number is indicated as SCH.
TRIPWITHPANEL
BELL  NOYES
AREA INFORMATION
AREAINFORMATION
INT PERIM
AREANO:-
INT BDRM PERIM
*UNUSED*
AUTOARM NO YES
BADZONES: BYP
BYP FORC  REF
AUTODIS NO YES
