TRAILER TOWING WEIGHTS (MAXIMUM TRAILER WEIGHT RATINGS) — NON-SRT
Engine GCWR Maximum GTW Maximum Trailer TW (See Note)
3.6L - RWD Light Duty Cooling 8,900 lb (4,037 kg) 3,500 lb (1,588 kg) 350 lb (159 kg)
3.6L - RWD 11,600 lb (5,262 kg) 6,200 lb (2,812 kg) 620 lb (281 kg)
3.6L - AWD Light Duty Cooling 8,900 lb (4,037 kg) 3,500 lb (1,588 kg) 350 lb (159 kg)
3.6L - AWD 11,600 lb (5,262 kg) 6,200 lb (2,812 kg) 620 lb (281 kg)
5.7L - RWD 13,100 lb (5,942 kg) 7,400 lb (3,357 kg) 740 lb (336 kg)
5.7L - AWD 13,100 lb (5,942 kg) 7,200 lb (3,266 kg) 720 lb (327 kg)
5.7L - AWD R/T Tow N Go 14,600 lb (6,622 kg) 8,700 lb (3,946 kg) 870 lb (395 kg)
Refer to local laws for maximum trailer towing speeds.
NOTE:
The trailer tongue weight must be considered as part of the combined weight of occupants and cargo, and should never exceed the weight referenced on the Tire And Loading
Information Placard
page 234. The addition of passengers and cargo may require reducing trailer tongue load and Gross Trailer Weight (GTW).
TRAILER HITCH RECEIVER COVER
REMOVAL — IF EQUIPPED
Your vehicle may be equipped with a trailer hitch
receiver cover, this must be removed to access the
trailer hitch receiver (if equipped). This cover is located
at the bottom center of the rear fascia/bumper.
1. Turn the two locking retainers located at the bottom
of the hitch receiver cover a quarter turn counter-
clockwise and pull bottom of the hitch receiver cover
outward (towards you).
2. Pull the bottom of the cover outward (towards you)
then downwards to disengage the tabs located at
the top of the hitch receiver cover to remove.
To reinstall the cover after towing, repeat the procedure
in reverse order.
Hitch Receiver Cover
1 — Hitch Receiver Cover
2 — Locking Retainers
Hitch Receiver Cover
118 STARTING AND OPERATING
