Cavity Cartridge Fuse Micro Fuse Description
* If Equipped
F60 – 15 Amp Blue TCM
F61 – 10 Amp Red PM Sensor *
F62 – 10 Amp Red A/C Clutch
F63 – 20 Amp Yellow Ignition Coils */ Ignition Coil Capacitors*
F64 – 25 Amp Clear Fuel Injectors / ECM
F65 – – Spare
F66 – 10 Amp Red Sunroof */ LRSM */ RVM / DSRC / USB Port / DTV*/WCP*
F67 – 15 Amp Blue CDM/UCI Port/USB Port
F68 – 20 Amp Yellow RR Wiper Mtr
F69 – 15 Amp Blue Spot Light Feed *
F70 – 20 Amp Yellow Fuel Pump Mtr
F71 – 30 Amp Green Amplifier */ ANCM *
F72 – 10 Amp Red ECM * / PCM *
F73 – 15 Amp Blue HID Headlamp RT *
F74 – – Spare
F75 – 10 Amp Red Dual Batt Ctrl *
F76 – 10 Amp Red ESP
F77 – 10 Amp Red DTCM / ELSD *
F78 – 10 Amp Red ECM / PCM * / EPS
F79 – – Spare
F80 – 10 Amp Red UGDO
F81 – 20 Amp Yellow Trlr Tow RT Turn / Stop *
F82 – 10 Amp Red SCCM / Cruise Control / DTV *
F83 – 10 Amp Red Fuel Door
F84 – 15 Amp Blue Cluster
F85 – 10 Amp Red ORC (Airbag)
F86 – 10 Amp Red ORC (Airbag)
F87 – 10 Amp Red Air Suspension Mod *
