FORMATTING MESSAGES
108 77144 Issue 8 August 2009
Note: Only one incremental count, one decremental count and one pallet count can be
used per message.
(3) When the information is entered into the
message it can be set to any text height or
select alternative font to use a
downloaded font (see page 91). The count
will increment every time the sensor is
triggered.
To set decremental box counting, follow the same steps ensuring decremental
counting is selected from the options menu.
When this is done, a similar values screen is
displayed showing the start value at 5842, this is the
default count down value and may be altered with a
new figure. The maximum in the case of
decremental counting is set to the figure the
decremental counting is to start from again. When
the count reaches zero, it will reset to its maximum
value. Finally, the boxes per inc. value is the
amount of boxes included in one decrement. To
confirm any changes press enter.
When the pallet counting option is chosen, the box
start value is set at its default value 1. In the pallet
count, the box maximum value is the amount of
boxes per pallet, the default is 99. The final value is
the pallet start the default is 1 and can be altered
by over typing the value with the cursor block.
BLANK MESSAGE
000
Count
1.
2.
3.
4.
DECREMENTAL COUNT
START 5842
MAXIMUM 9999
BOXES PER INC. 01
PALLET COUNT
BOX START 1
BOX MAXIMUM 99
PALLET START 001
