FORMATTING MESSAGES
77144 Issue 8 August 2009 111
(3) If the EAN 128 option has been selected,
there are six icons that can be used in this bar
code:
•Real time commands
•Sell by date
•Counting
•Variable
•Edit
•Function 1
These icons work in exactly the same way as the attribute icons on the
message editor.
For Variable information, see page 82.
If the bar code does not allow variable
information, simply enter the required bar code
number.
Note: Only one incremental, decremental and
pallet count are allowed per message.
(4) When the bar code information has been
entered, press the enter key to confirm.
Before the information is entered into the
message editor, the control unit will prompt
if the message should be human readable
and whether bearer bars are required. To
select these options, use the cursor keys to
toggle between Y/N and to move from one
line to another. When finished press the
enter key to confirm. The differences
between both these options are shown in the
two different samples on the following page.
BAR CODES
>EAN 128
CODE 128
ITF 14
EAN 13
UPC A
UPC E
EAN 128
HUMAN READABLE /N
BEARER BARS Y/N
OK
