BASIC OPERATIONS
77144 Issue 8 August 2009 61
ROOT LEVEL, MENU
BAR ICONS
NAME & DESCRIPTION
Box count, this icon allows the operator to record
the number of products passing on the production
line.
Choose language, allows the operator to select
from the list of operating languages.
Options screen, allows the operator to enable
external peripherals, e.g. a shaft encoder or
external photo cell.
Enable user password, the operator can restrict
access to the control unit by installing a user
password so that the settings cannot be changed.
Wipe, to completely erase the control unit
memory, this icon will delete all saved messages
and downloaded logos. The printer will revert to
its default factory settings.
Orientation, to invert and reverse the message.
The print direction is automatically changed.
Ink Cost Calculator, used to calculate the cost
and amount of ink used for a specified message.
Var iab l e s , add either a prompted or external
variable into a message.
External Setup, used to setup parameters of
external variables - preamble, postamble &
timeout.
Shaft Encoder Sensing, measures S/E pulses to
ensure not being overdriven for current DPI.
To Next Page
