3.10.2. Manual door open:
This has two moving parts which slide over the front panel of the dryer to open and close the door. The
upper moving part will move upwards when the door is opened and downwards when the door is
closed. The lower moving part will move downwards when the door is opened and upwards when the
door is closed.
Hold the horizontal bar and pull upwards to open the door, pull downwards to close the door.
MANUAL DOOR OPEN AUTOMATIC DOOR OPEN
3.10.3. Emergency door open (only for Automatic Guillotine):
In the event of a power failure, to prevent the risk of spontaneous combustion, it is possible to open the
door as follows. First, disconnect the power supply at the main switch at the rear of the machine in case the
power is restored during the operation. If there are any persons, objects or garments trapped between the
two doors which may block the door due to the operation of the photocells, proceed in the same way;
Behind the left side panel there is a key which permits the elastic coupling to be operated in order to
move the spindle manually and open the door. (See figure below):
