Doosan D35C-5 User Manual

Operation Section
-105-
Table 2. MI-07 Diagnostic Fault Codes (Flash Codes)
DFC PROBABLE FAULT FAULT ACTION * CORRECTIVE ACTION FIRST CHECK
12
NONE
Signifies the end of one pass
through the fault list
NONE
None, used as end of the fault list
identification
131
Inj1Open
Gasoline Injector 1 open
circuit, broken injector 1 wire
or defective injector
(1) TurnOnMil
(2) Disable
LiquidO2Ctrl
(3) Delayed
EngineShutdown
Check INJ1 wiring for an open circuit
SECM (Signal) A5 to Injector 1 Pin A
Switched 12V to Injector 1 Pin B
Check Injector 1 Resistance, 12 to14
ohms (cold)
132
Inj2Open
Gasoline Injector 2 open
circuit, broken injector 2 wire
or defective injector
(1) TurnOnMil
(2) Disable
LiquidO2Ctrl
(3) Delayed
EngineShutdown
Check INJ2 wi
r
ing for an open circuit
SECM (Signal) A8 to Injector 2 Pin A
Switched 12V to Injector 2 Pin B
Check Injector 2 Resistance, 12 to14
ohms (cold)
133
Inj3Open
Gasoline Injector 3 open
circuit, broken injector 3 wire
or defective injector
(1) TurnOnMil
(2) Disable
LiquidO2Ctrl
(3) Delayed
EngineShutdown
Check INJ3 wiring for an open circuit
SECM (Signal) A4 to Injector 3 Pin A
Switched 12V to Injector 3 Pin B
Check Injector 3 Resistance, 12 to14
ohms (cold)
134
Inj4Open
Gasoline Injector 4 open
circuit, broken injector 4 wire
or defective injector
(1) TurnOnMil
(2) Disable
LiquidO2Ctrl
(3) Delayed
EngineShutdown
Check INJ4 wiring for an open circuit
SECM (Signal) A7 to Injector 4 Pin A
Switched 12V to Injector 4 Pin B
Check Injector 4 Resistance, 12 to 14
ohms (cold)
141
(14)
ECTRangeLow
Coolant Sensor failure or
shorted to GND
(1) TurnOnMil
(2) DelayedEngine
Shutdown
Check ECT sensor connector and wiring
for a short to GND
SECM (Signal) Pin B15 To ECT Pin 3
SECM (Sensor GND) Pin B1 to ECT Pin 1
SECM (System GND) Pin A16, B17
151
(15)
ECTRangeHigh
Coolant sensor disconnected
or open circuit
(1) TurnOnMil
(2) DelayedEngine
Shutdown
Check if ECT sensor connector is
disconnected or for an open ECT circuit
SECM (Signal) Pin B15 to ECT Pin 3
SECM (Sensor GND) Pin B1 to ECT Pin 1
