Doosan D35C-5 User Manual

Operation Section
-157-
Adjustment of Armrest
By using 2 knobs, adjust the position of the armrest
to give the operator the best comfortable position of
arm.
knob #1 - Forward and backward adjustment
knob #2 - Up and down adjustment.
Forward and Backward Adjustment
1. Loosen the knob bolt(1)..
2. Adjust the position of armrest forward or
backward.
3. Tighten the knob bolt(1) to be locked tightly.
Up and Down Adjustment
To move the armrest down, turn the knob(2)
counterclockwise
.
To move the armrest up, turn the knob(2)
clockwise.
2
1
1
2
2
