Maintenance Section
-241-
Every 2500 Service Hours or 15 Months
You must read and understand the warnings and instructions contained in the Safety section of this manual,
before performing any operation or maintenance procedures.
Hydraulic Oil - Check, Clean,
Change
WARNING
Hot oil and components can cause personal
injury. Do not allow hot oil or components to
contact skin.
Park the lift truck level with the forks lowered,
parking brake engaged, transmission in NEUTRAL
and the engine stopped.
1. Remove the hydraulic tank drain plug. Allow the
oil to drain into a suitable container. Clean and
install the plug.
2. Remove the dipstick/filter cap assembly.
3. Fill the hydraulic tank. See topic “Refill
Capacities”. Install the dipstick/filter cap
assembly.
4. Start the engine and operate the hydraulic
controls, and the steering system, through a
few cycles to fill the lines. Look for oil leaks.
5. Stop the engine and check the oil level. With all
cylinders retracted, maintain the oil level to the
FULL mark on the dipstick/filter cap assembly.
Inspect Battery System
1. Clean battery outer surfaces with a mixture of
baking soda and water.
2. Inspect battery outer surfaces for damage and
replace as necessary.
3. Remove battery cable and clean, repair and/or
replace as necessary.
