Specifications
CHARACTERISTICS
1 MANUFACTURER
DOOSAN DOOSAN
2 MODEL
D20S-5
(YANMAR,TIER2)
D25S-5
(YANMAR,TIER2)
3 CAPACITY at rated load center kg 2000 2500
4 LOAD CENTER distance mm 500 500
5 POWER TYPE electric, diesel, gas, LPG-gas diesel diesel
6 OPERATOR TYPE stand-on, ride-seated rider-seated rider-seated
7 TIRES C=cushion, P=pneumatic p p
8 WHEELS(x=driven) number of front/rear 2/2 2/2
DIMENSIONS
9
LIFT WITH STD
TWO-STAGE MAST
maximum fork height with rated load mm 3230 3230
10 free lift mm 152 152
11 FORK CARRIAGE ISO class II II
12
FORKS
thickness x width x length mm 40x100x1050 40x100x1050
13 fork spacing (maximum x minimum) mm 275x1035 275x1035
14 TILT OF MAST forward/backward deg 6/10 6/10
15
OVERALL
DIMENSIONS
length to fork face mm 2530 2595
16 width mm 1170 1170
17 mast lowered height mm 2175 2175
18 mast extended height mm 4490 4490
19 overhead guard height mm 2183 2183
20 seat height mm 1026 1026
21 OUTSIDE TURNING RADIUS mm 2220 2265
22 LOAD MOMENT CONSTANT mm 480 480
23 90。 STACKING AISLE mm 2700 2745
23
a
90。 INTERSECTING AISLE
mm 1970 2000
PERFORMANCE
24
SPEED
travel, loaded/unloaded km/hr 21/21.5 21/21.5
25 lift, loaded/unloaded mm/s 530/550 520/550
26 lowering, loaded/unloaded mm/s 510/460 510/460
27 DRAWBAR PULL at 1.6km/hr, loaded/unloaded kg 1765 1740
28 GRADEABILITY at 1.6km/hr, loaded/unloaded % 33 28
29 ACCELERATION
time reached at max speed,
loaded/unloaded
sec
WEIGHT
30 TOTAL WEIGHT at unloaded kg 3580 3950
31
AXLE LOAD
at loaded, front/rear kg 4930/650 5660/790
32 at unloaded, front/rear kg 1720/1860 1650/2300
CHASSIS
33
TIRES
number of front/rear 2/2 2/2
34 front size 7.00x15-12 7.00x15-12
35 rear size 6.50x10-10 6.50x10-10
36 WHEEL BASE mm 1625 1625
37 TREAD front/rear mm 975/1000 975/1000
38
GROUND
CLEARANCE
at loaded, the lowest point mm 115 115
39 at loaded, center of wheelbase mm 143 143
40 SEVICE BRAKE foot/hyd foot/hyd
41 PARKING BRAKE hand/mech hand/mech
DRIVE
42 BATTERY voltage/capacity V/AH 12/85 12/85
43
ENGINE
manufacturer/model YANMAR/4TNV98 YANMAR/4TNV98
44 rated output / rpm kw(hp) 46.3(62.1)/2200 46.3(62.1)/2200
45 max. torque / rpm N-m(lb•ft) 240(177)/1320 240(177)/1320
46 cycle/cylinders/displacement cc 4/4/3319 4/4/3319
47
TRANSMISSION
type powershift powershift
48 number of speeds forward/reverse 1/1 1/1
49
OPERATING
PRESSURE
system/attachment bar 181/156 195/156
50 NOISE LEVEL
equivelent continuous sound
pressure level (Leq) at operator's ear
(DI : BITA/CE prEN 12053)
dB(A)
