Specifications
CHARACTERISTICS
1 MANUFACTURER DOOSAN DOOSAN
2 MODEL GC35S-5 GC40S-5
3 CAPACITY at rated load center kg 3500 4000
4 LOAD CENTER distance mm 500 500
5 POWER TYPE electric, diesel, gas, LPG-gas LPG LPG
6 OPERATOR TYPE stand-on, ride-seated rider-seated rider-seated
7 TIRES C=cushion, P=pneumatic C C
8 WHEELS(x=driven) number of front/rear 2/2 2/2
DIMENSIONS
9 LIFT WITH STD maximum fork height with rated load mm 3000 3000
10 TWO-STAGE MAST free lift mm 160 160
11 FORK CARRIAGE ISO class III III
12 FORKS thickness x width x length mm 50x150x1220 50x150x1220
14 TILT OF MAST forward/backward deg 5/6 5/6
15 length without forks mm 2718 2762
16 width mm 1270 1270
17 OVERALL mast lowered height mm 2195 2195
18 DIMENSIONS mast extended height mm 4115 4115
19 overhead guard height mm 2155 2155
20 seat height mm 1080 1080
21 OUTSIDE TURNING RADIUS mm 2360 2400
22 LOAD MOMENT CONSTANT mm 505 505
PERFORMANCE
23 travel, loaded/unloaded km/hr 15/15 15/15
24 SPEED lift, loaded/unloaded mm/s 500/550 480/550
25 lowering, loaded/unloaded mm/s 530/450 500/450
27 GRADEABILITY at 1.6km/hr, loaded/unloaded % 27 24
WEIGHT
28 TOTAL WEIGHT at unloaded kg 5470 5850
29 at loaded, front/rear kg 7970/1000 8690/1160
30
AXLE LOAD
at unloaded, front/rear kg 2230/3240 2130/3720
CHASSIS
31 number of front/rear 2/2 2/2
32 TIRES front size 22x9x16 22x9x16
33 rear size 18x6x12-1/8 18x7x12-1/8
34 WHEEL BASE mm 1630 1630
35 TREAD front/rear mm 1042/1044 1042/1044
36 GROUND at loaded, the lowest point mm 130 130
37 CLEARANCE at loaded, center of wheelbase mm 130 130
38 SEVICE BRAKE foot/hyd foot/hyd
39 PARKING BRAKE hand/mech hand/mech
DRIVE
40 BATTERY voltage/capacity V/AH 12/ 12/
41 manufacturer/model GM 4.3 V6 GM 4.3 V6
42 ENGINE rated output / rpm PS/rpm 95.2/2500 95.2/2500
43 max. torque / rpm kg.m/rpm 30.6/1500 30.6/1500
44 cycle/cylinders/displacement cc 4/6/4294 4/6/4294
45 type powershift powershift
46
TRANSMISSION
number of speeds forward/reverse 2/2 2/2
47 OPER PRESSURE system/attachment bar 190/140 210/140
