Doosan DB33A - Camshaft Assembly; Rocker Arm Bushing; Clearance between Rocker Arm Shaft and Bushing

33
Rocker arm bushing (mm)
Clearance between rocker arm shaft and bushing
(mm)
2.3.7. Camshaft Assembly
Inspect all disassembled parts for wear, damage and
any abnormalities.
End play (mm)
Camshaft journal diameter (mm)
¡¡ ‹
Camshaft
¡¡ ‹
Cam gear
¡¡ ‹
Thrust plate
Camshaft gear
Thrust plate
Camshaft
Feeler gauge
Standard
19.01~19.03
(.748¡›.749 in)
Limit
19.05
(.75 in)
Standard
0.01¡›0.05
(.0004¡›.0020 in)
Limit
0.2
(.0079 in)
Standard
0.050¡›0.114
(.0020¡›.0045 in)
Limit
0.2
(.0079 in)
Standard
55.94¡›55.97
(2.202~2.204 in)
Limit
55.60
(2.189 in)
