Cooling fan belt (13)
Adjust the cooling fan belt tension.
¡¡
‹
Starter motor (9)
¡¡
‹
Exhaust manifold (11)
Carefully install the gasket with the "TOP" mark side
facing up.
Install either end of the distance tube in the spot
facing.
Tighten the exhaust manifold and gasket fixing bolts in
numerical order as shown in the figure.
Refer to Maintenance for
the fan bolt tension adjustment
"TOP" mark
Distance tube
Torque (kgƒUm)
8.6
(62.2 lb¡⁄ft)
Torque (kgƒUm)
2.6
(18.8 lb¡⁄ft)
