Doosan DB33A - Flywheel and Housing(Rear Oil Seal); Ring Gear Replacement; Flywheel Housing Oil Seal Replacement

43
Installer
Ring gear replacement
Removal : Use a brass bar and hammer
-Strike around the edges of the ring gear with a
hammer and brass bar to remove it.
Installation :
-Heat the ring gear evenly with a gas burner to invite
thermal expansion.
Do not allow the temperature of the ring gear to
exceed 200¡ (390¢ )
-Use a hammer to install the ring gear when it is
sufficiently heated.
Flywheel housing oil seal replacement
Removal : Use a pry bar and hammer.
Installation : Use a oil seal installer.
2.3.13. Flywheel and Housing(Rear Oil Seal)
¡¡ ‹
Flywheel thickness (Friction face) (mm)
Friction face
Crankshaft
assembly
face
Standard
33.4¡›33.6
(1.315~1.323 in)
Limit
32.5
(1.280 in)
If the crankshaft contact area wears excessively,
move the contact area with a oil seal spacer. Install
new oil seal and discard the used one.
Spacer
Oil seal
