Inspection and repair
Make the necessary adjustments, repairs and part
replacements if excessive wear or damage is found
through inspection.
Visually inspect the disassembled parts for excessive
wear and damage.
Oil pump cover and oil pump drive gear clearance.
Cover and driven gear clearance
Drive gear shaft diameter (mm)
Standard
16.0
Limit
Limit (mm)
0.18
(.007 in)
Limit (mm)
0.12
(.005 in)
15.9
(.626 in)
