Doosan DB33A - Thrust Bearing; Tappet; General Components; Rocker Arm, Bracket and Shaft Assembly

25
¡¡ ‹
Thrust bearing (18)
Remove the thrust bearing with steel wire.
¡¡ ‹
Tappet (21)
Remove the tappets and mark the cylinder number
each tappet.
(Be careful against the damages)
Wire
Intake
Exhaust
Mark the cylinder No
2.2.4. General Components
¡¡ ‹
Rocker arm, Bracket and shaft assembly
<Disassembly steps>
1. Bracket
2. Rocker arm
3. Spring
4. Rocker arm shaft
