Doosan DB33A - Timing Gear Case Cover; Engine Reassembly; Minor Components

44
2.3.14. Timing Gear Case Cover
Oil seal replacement
Installation : Installer
Installer
2.4. Engine Reassembly
2.4.1. Minor Components
¡¡ ‹
Piston and connecting-rod assembly
<Disassembly steps>
1. Piston
2. Piston pin
3. Snap ring
4. Piston ring
5. Connecting rod
1
2
3
4
3
5
Important operation
¡¡ ‹
Piston (1)
Use a piston heater to heat the piston approximately
60¡ (140¢ )
Piston heater
