66
Important operation
¡¡ ‹
Impeller (2)
Removal : Remover
¡¡ ‹
Pulley center (3)
Remove the pulley center using a bench press and a
bar.
¡¡ ‹
Snap ring (4)
Remove the snap ring using a snap ring plier.
¡¡ ‹
Shaft, bearing and spacer (5)
Remove the shaft and bearings using a bench press
and suitable remover.
¡¡ ‹
Seal unit, Washer and seal (6)
Remove the seal unit using a bench press and
suitable remover.
Pully center
Bench press
