Doosan DX480LC - Torque Values for Hose Clamps

SP000813Standard Torques
Page 10
TORQUE VALUES FOR HOSE
CLAMPS
The following chart provides the tightening torques for hose
clamps used in all rubber applications (radiator, air cleaner,
operating lever boots, hydraulic system, etc.).
Clamp Type And Size
Torque
Radiator, Air Cleaner, Boots, Etc. Hydraulic System
Kilogram Meter
(kg
•m)
Inch Pounds
(in lb)
Kilogram Meter
(kg•m)
Inch Pounds
(in lb)
"T" Bolt (Any Diameter) 0.68 - 0.72 59 - 63 ------- ------
Worm Drive - Under
44 mm (1-3/4 in) Open
Diameter
0.2 - 0.3 20 - 30 0.5 - 0.6 40 - 50
Worm Drive - Over 44 mm
(1-3/4 in) Open Diameter
0.5 - 0.6 40 - 50 ------- ------
Worm Drive - All
"Ultra-Tite"
0.6 - 0.7 50 - 60 0.5 - 0.6 40 - 50
