Doosan DX480LC - Air Conditioner System

SP002030
Page 77
Electrical System
AIR CONDITIONER SYSTEM
Outline
Solid-type heater and air conditioner are installed in the cover
behind the operator's seat.
Temperature of the operator's room is adjusted automatically to
the temperature set by operator.
(Please refer to the Operation Manual for detailed full automatic
control.
FG013857
A
A
C
B
C
Figure 69
