Doosan DX480LC - Operation

SP002030Electrical System
Page 24
OPERATION
Instruments
Function Display
Sensor Specification
Input Terminal Input Specification
Coolant
Temperature
ECU-CAN
Communication
Fuel Level
CN3-7
CN3-8
1/10 LCD (Red Zone)
Blinking → over 5K ohms
FULL → under 525 ohms
Hydraulic Oil
Temperature
CN3-9
CN3-10
40°C (104°F) → 1,397 ohms
50°C (122°F) → 1,139 ohms
60°C (140°F) → 881 ohms
94°C (201°F) → 190 ohms
96°C (205°F) → 177 ohms
(When reading increase)
Flow
Adjusting
(Output
Terminal)
CN1-19
CN1-20
48 l/min → 615 mA
70 l/min → 583 mA
90 l/min → 555 mA
130 l/min → 495 mA
(Default Set)
210 l/min → 376 mA
244 l/min → 260 mA
C
H
FG000550
Blue
White Red
107°C
102°C
41°C
61°C
E
F
FG000552
Blue
Red Full
1/10
C
H
FG000551
Blue
White Red
96°C
94°C
40°C
50°C
FG000553
(None)
48
70
90
110
130
150
170
190
210
230
244
