SP002026Specification for DX300LCA
Page 12
WORKING RANGE
WARNING
The actual value for dimension "L" Digging Reach, depends
on the stability and support provided by ground conditions.
Digging too far underneath the excavator if soil conditions
are wet, loose or unstable can collapse ground support,
which could cause injury and/or equipment damage.
0
1
2
3
4
5
6
7
8
9
10
11
-1
-2
-3
-4
-5
-6
-7
-8
C
D
F
A
E
I
B
H
G
G.L
012 43 567891011
FG001449
Figure 2
