Specification for DX300LCA
Dim.
Boom Type One Piece 6.245 m (20.5 ft)
Arm Type
3.1 m
(10.17 ft)
2.5 m
(8.2 ft)
3.75 m
(12.3 ft)
Bucket Type (PCSA)
1.27
m
3
(1.66 yd
3
)
1.50
m
3
(1.96 yd
3
)
1.75
m
3
(2.29 yd
3
)
A Max. Digging Reach
10,745 mm
(35' 3")
10,170 mm
(33' 4")
11,270 mm
(37' 0")
B
Max. Digging Reach
(Ground)
10,550 mm
(34' 7")
9,970 mm
(32' 9")
11,090 mm
(36' 5")
C Max. Digging Depth
7,380 mm
(24' 3")
6,780 mm
(22' 3")
8,030 mm
(26' 4")
D Max. Loading Height
7,240 mm
(23' 9")
6,910 mm
(22' 8")
7,345 mm
(24' 1")
F Max. Digging Height
10,310 mm
(33' 10")
9,950 mm
(32' 8")
10,390 mm
(34' 1")
G Max. Bucket Pin Height
8,855 mm
(29' 1")
8,525 mm
(28' 0")
8,960 mm
(29' 5")
H Max. Vertical Wall
6,200 mm
(20' 4")
5,425 mm
(17' 10")
6,690 mm
(21' 11")
I Max. Radius Vertical
6,820 mm
(22' 5")
6,545 mm
(21' 6")
7,045 mm
(23' 1")
J Max. Depth to 8 ft Line
7,185 mm
(23' 7")
6,505 mm
(21' 4")
7,850 mm
(25' 9")
K Min. Radius 8 ft Line
2,990 mm
(9' 10")
2,965 mm
(9' 9")
2,930 mm
(9' 7")
L Min. Digging Reach
625 mm
(2' 1")
1,995 mm
(6' 7")
- 305 mm
(- 1' 0")
M Min. Swing Radius
4,055 mm
(13' 4")
4,060 mm
(13' 4")
4,060 mm
(13' 4")
