Cylinders
MODEL CYLINDER
øA
øB ( ±0.1) E
F
Part
MODEL
(CYLINDER)
DX300LC /
DX300LCA
BOOM
90.0 mm
(3.54 in)
105.0 mm
(4.13 in)
40.0 mm
(1.58 in)
7.0 mm
(0.28 in)
ARM
90.0 mm
(3.54 in)
105.0 mm
(4.13 in)
40.0 mm
(1.58 in)
6.5 mm
(0.26 in)
S/ARM
BUCKET
90.0 mm
(3.54 in)
105.0 mm
(4.13 in)
40.0 mm
(1.58 in)
7.0 mm
(0.28 in)
S/BUCKET
DX340LC /
DX350LC
BOOM
100.0 mm
(3.94 in)
115.0 mm
(4.53 in)
45.0 mm
(1.77 in)
7.5 mm
(0.30 in)
OPT BOOM
ARM
100.0 mm
(3.94 in)
115.0 mm
(4.53 in)
45.0 mm
(1.77 in)
7.5 mm
(0.30 in)
OPT ARM
BUCKET
100.0 mm
(3.94 in)
115.0 mm
(4.53 in)
45.0 mm
(1.77 in)
7.5 mm
(0.30 in)
OPT BUCKET
DX420LC
BOOM
110.0 mm
(4.33 in)
130.0 mm
(5.12 in)
70.0 mm
(2.76 in)
11.0 mm
(0.43 in)
ARM
110.0 mm
(4.33 in)
130.0 mm
(5.12 in)
70.0 mm
(2.76 in)
11.0 mm
(0.43 in)
BUCKET
110.0 mm
(4.33 in)
130.0 mm
(5.12 in)
70.0 mm
(2.76 in)
11.0 mm
(0.43 in)
-0.05
-0.15
+0.05
0
