Doosan DX480LC - Page 367

SP000031
Page 11
Swing Motor
Reference
Number
Description
1 Body
2 Oil Seal
3 Roller Bearing
4 Snap Ring
5 Shaft
6 Parallel Pin
7 Stop Ring
8 Shoe Plate
9 Rotary Kit
9A Cylinder Block Kit
9Aa Cylinder Block
9Ab Valve Plate
9B Spring
9C Retainer Kit
9Ca Ball Guide
9Cb Set Plate
9D Piston KT
14 Friction Plate
15 Plate
16 Brake Piston
17 O-ring
18 Spring
19 Cover
20 Needle Bearing
21 Parallel Pin
23 Socket Bolt (M20x2.5)
24 Poppet
25 Spring
26 Plug
27 O-ring
28 Reductionless Valve Assembly
29 Plug
30 O-ring
31 O-ring
32 Back up Ring
33 Relief Valve Assembly
33A O-ring
33B Back up Ring
33C O-ring
33D O-ring
33E Back up Ring
34 Time Delay Valve Assembly
34A O-ring
34B O-ring
35 Socket Bolt (M6x75)
36 Plug
37 O-ring
38 O-ring
39 Bushing
Reference
Number
Description
