SP002026
Page 15
Specification for DX300LCA
Overall Shipping Height (to top
of cylinder hose)
3,345 mm (11')
Track Shipping Length 4,940 mm (16' 2")
Transport Trailer Capacity 30 tons (33 short tons), minimum load capacity
Transport Loading Ramp Allowable
Slope
15° angle CAUTION: Refer to Transport Maximum Procedure for Safe
Shipping Instructions.
