3.7 Audio Menu
• The following menu can be used to set up the audio parameters:
Sub-Menu Value Description
Input Auto
SDI
HDMI
Audio input format setting
Auto: Audio input is the same
as video input.
Delay X frames
-1 to +2 frames (0) Delay Audio
to Video. Can be adjusted in .5
frame increments.
Level -18, -12, -6, 0, +6, +12,
+18 dB
(0) Audio Output level setting.
HDMI Out
Channel
Auto (All 8 audio
channels)
2 (1,2)
4 (1,2,3,4)
6 (1,2,3,4,5,6)
8 (1,2,3,4,5,6,7,8)
Off
Set the HDMI audio output
mode
Auto: All audio inputs will be
present on the HDMI output.
2, 4, 6, 8: Total number of audio
channels to be present on the
HDMI output.
Off: No embedded HDMI audio
on output.
SDI Out Groups
Auto (All 16 audio
channels)
1 (1,2,3,4)
1+2 (1,2,3,4,5,6,7,8)
1+2+3
(1,2,3,4,5,6,7,8,9,10,11,1
2)
1+2+3+4
(1,2,3,4,5,6,7,8,9,10,11,1
2,13,14,15,16)
Off
Set the embedded SDI active
audio groups.
Auto: All audio inputs will be
present on the SDI output.
Each group has 4 audio
channels, when 1+2+3+4 is
selected, all 16 audio channels
will be present.
Off: No Embedded SDI audio
on output.
