DORMA PORTEO
WN 057472 45532 02/08
Operation
0
0
0
0
0FF
0
N
0
0
0
0FF
0N
Operating type/functions
Power switch
OFF = ower supply inactivated
0N = Power supply activated
Program switch
Power switch in "ON" position.
.
PORTEO door assistant
P
I = PowerMotion
0 = OFF
II = PermanentOpen
Program switch in "O" (OFF) position
"0"
PORTEO door assistant
Program switch in "I" position = "PowerMotion"
"PowerMotion"
Please note!
Program switch in position "II" = "PermanentOpen"
Set program switch in position "PermanentOpen".
"PermanentOpen"
OPTION - "PermanentOpen" with flip-flop function, in program switch
position "PowerMotion" with pushbutton or hand-held remote control as
activator.
When in position:
- The electric functions of the are switched off.
The does not have a function
The door can be accessed manually
Either via door handle or key
When in position, the opening and closing cycles are
controlled by activators.
When an opening pulse is triggered the door opens automatically and
closes automatically on expiry of the preset hold-open time
s c to sec
In case an opening pulse is triggered during the hold-open
time (while the door is in “open” position), the hold-open time is reset,
that means it starts from 0 sec.
When in position
- The door travels to "open" position and remains in this position, until
another operating type is adjusted with the aid of the program switch.
-.
.
.
-
(5 e . 30 .).
Before activating the program switch, you have to ensure that the door is neither closed nor
locked.Otherwise the door cannot leave "closed” position.
Press pushbutton twice in short succession or press the programmed
pushbutton on the hand-held transmitter once:
- the door travels to "open" position and remains in this position.
The door closes as soon as the pushbutton is pressed again twice in
short succession or the programmed pushbutton on the hand-held
transmitter is activated again for one time.
GB 20
