Dorma PORTEO User Manual (English)

Other manuals for Dorma PORTEO

Assembly Instruction20 pages

Quick Start Manual2 pages

Questions and Answers:

D
Danielle MooneyAug 1, 2025
What to do if the Dorma PORTEO LED light is off and the door doesn't respond?
- V
  Vanessa MurphyAug 1, 2025
  If the LED light indicator is off and the door doesn't respond, it could be due to several reasons. First, ensure that the power switch is on. Check all cable connections to make sure they are securely connected. Inspect the cable for any damage and replace it if necessary. Verify that the power plug is properly inserted. If none of these steps resolve the issue, the door assistant may be defective and require replacement.
P
peckkellyAug 5, 2025
Why is the LED light indicator blinking and the Dorma PORTEO not responding?
- J
  jthomasAug 5, 2025
  A blinking LED light indicator with no door response could mean that the learning cycle was not performed correctly; in this case, restart the learning cycle. It may also indicate external malfunctions, which can be addressed by resetting the system: first, set the program switch to the "0" position, then to the desired mode. Next, switch the power off, and then back on after 5 seconds. If the electric strike is not opening the door, set the DIP switch A to the "ON" position and check, repair, or replace the electric strike and connections as needed. If the problem persists, the door assistant may be defective and require replacement.
E
Elizabeth JohnsonAug 9, 2025
What to do if the Dorma PORTEO Door Opening System LED light is on, but the door does not respond?
- L
  lucasanthonyAug 9, 2025
  If the LED light is illuminated but the door isn't responding, check the program switch position. If it's set to "0" (central position), set it to the desired position. If it's set to "II" (Permanent Open), switch it to "I". Also, check if PowerLessmode is adjusted and adjust via potentiometer 1. If the door was opened via the flip-flop function, close it by giving a new pulse (press the pushbutton twice in quick succession). If the problem persists, the door assistant may be defective and need replacement.
C
Catherine PayneAug 14, 2025
What causes a Dorma Door Opening System to not reach the adjusted opening angle?
- M
  Matthew RhodesAug 14, 2025
  If the door doesn't reach the adjusted opening angle, there might be an obstacle in the door's driving phase; remove any obstructions. Alternatively, the opening angle may be incorrectly adjusted, so repeat the learning cycle. Loose screws on the slide channel can also cause this issue; tighten them thoroughly.
J
James StoneAug 18, 2025
Why does the Dorma PORTEO Door Opening System open beyond the adjusted opening angle?
- R
  rachel55Aug 18, 2025
  If the door opens beyond the adjusted opening angle, it could be due to an obstacle in the door's driving phase, or the opening angle may be incorrectly adjusted. Remove any obstacles and repeat the learning cycle. Also, check if the screws of the slide channel are loose and tighten them thoroughly.
R
Richard VargasAug 22, 2025
What should I do if my Dorma PORTEO Door Opening System stops during a cycle?
- M
  Monica HermanAug 22, 2025
  If the door stops during a cycle, inspect the door and driving phase for any obstructions preventing smooth operation. Remove any causes of unsmooth running. Also, check the slide channel for dirt or wear and clean or replace it if needed.
R
Ryan QuinnAug 27, 2025
Why does the Dorma PORTEO open automatically after closing?
- E
  elijahbaileyAug 27, 2025
  If the door opens automatically following a closing cycle, the screws of the slide channel might be loose. Ensure that you tighten the screws thoroughly.

Dorma PORTEO Specifications

General

Product Type	Automatic swing door operator
Type	Electromechanical
Max. Door Weight	100 kg
Max. Door Width	1100 mm
Protection Class	IP20
Opening Speed	Adjustable
Closing Speed	Adjustable
Hold-open Time	Adjustable
Operating Temperature	-15°C to +50°C
Application	Interior doors
Opening Angle	110 degrees
Power Supply	230 V AC, 50 Hz
Safety Features	Obstacle detection

Summary

General Safety Instructions

Intended Application

Describes the product's designed use and limitations for safe operation.

Product-Specific Characteristics

Details features relevant to the product's application and design.

Standards, Laws, Codes, and Regulations

Outlines applicable industry standards and legal requirements for the product.

Limitation of Liability

States conditions under which the manufacturer's liability is limited.

Documentation Requirements

Emphasizes the importance of following provided documentation for safety.

General Installation Information

Provides essential guidelines for safe and proper installation procedures.

Improper Application Guidelines

Specifies unsuitable applications and environments for the product.

Disposal Information

Instructions on how to properly dispose of the product at the end of its life.

Standard Scope of Delivery

Included Documentation

Lists the types of documentation provided with the product for installation and use.

Status on Delivery and Accessory Selection

Required Accessories by Mounting Type

Details accessories needed based on the chosen installation method.

Required Tools for Installation

Lists the necessary tools for performing the installation correctly.

"Door basics" Technical Terms

Function and Adjustments Overview

General Information on Functionality

Provides a high-level overview of the door assistant's purpose and basic operation.

Functionality Description

Explains the operational mechanisms of the door assistant, including activators.

Settings and Adjustment Parameters

Lists key parameters that can be configured for optimal door operation.

Approach to Installation and Commissioning

Determine Power Connection Method

Outlines options for connecting the device to power, including Plug&Go.

Perform Mounting Procedure

Describes the steps involved in physically installing the door assistant using diagrams.

Commission the PORTEO Door Assistant

Details the process for initial setup and calibration after installation.

Requirements for Standard Commissioning

Standard Commissioning Process

Requirements for Standard Commissioning

Lists prerequisites before starting the standard setup procedure.

Determine Swing Direction

Explains how to set the door's opening direction during the commissioning process.

Determine 'Open' Position

Details how to set the door's fully open position during commissioning.

Extended Commissioning Procedure

Preparations for Extended Commissioning

Covers initial steps like closing the door and selecting accessories before configuration.

Extended Commissioning Learning Cycle

Describes the automatic learning phases for advanced configurations.

Determine Swing Direction

Sets the door's opening direction during the learning cycle.

Teach-in Mounting and Arm Version

Configures the system based on the chosen mounting and arm type.

Teach-in Door Width

Sets the door's width parameter for optimal operation during learning.

Determine 'Open' Position

Sets the door's final open position during the learning cycle.

Operation Modes and Functions

Power and Program Switch Settings

Explains how to use switches to select operating modes like PowerMotion.

PowerMotion Operation Mode

Details the functionality of the PowerMotion setting for automatic door control.

PermanentOpen Operation Mode

Describes the behavior of the PermanentOpen mode for continuous door opening.

PowerLess Operation Mode

Explains the manual opening and automatic closing feature with minimal effort.

Push&Go Operation Mode

Details the function triggered by a slight manual push for automatic opening.

Obstacle Recognition and Vandalism Mode

Covers safety features for detecting obstructions and preventing misuse.

Latching Action Function

Describes the feature that accelerates closing at the end of the cycle.

Adjustments and Settings

Adjusting the PowerLess Mode

How to configure the PowerLess function using potentiometers for manual operation.

Adjusting Door Speed

Setting the opening and closing speed of the door via potentiometer.

Adjusting Hold-Open Time

Configuring how long the door remains open after activation.

Adjusting Wall Blanking

Setting the range for sensor-based wall blanking for safety.

Adjusting for Electric Strike

Configuration steps when an electric strike is used as an accessory.

Adjusting Latching Action

Fine-tuning the latching action feature for smooth closing.

Connection Diagrams

Connection Diagram for Connection Unit

Shows wiring for the main unit and external accessories like sensors.

Connection Diagram for Electric Strike

Illustrates wiring for integrating an electric strike with the door assistant.

Direct Power Supply Installation

Accessories Overview

Mounting Plates and Brackets

Describes plates and brackets for mounting the slide channel to door frames.

Glass Door Clamping Rail

Details the accessory for fixing the slide channel to all-glass doors.

Electric Strike and Safety Sensors

Information on optional electric strikes and safety sensors for enhanced functionality.

Manual Release Switch

Describes an optional manual override switch for the door system.

Hand-held Transmitter RC-T System

Functions and Programming

Explains how to use and program the RC-T remote control for door operation.

Commissioning, Care, and Maintenance

Inspection and Acceptance Test Procedures

Outlines initial checks required before the first commissioning of the door assistant.

Regular Maintenance and Inspection Schedule

Details the requirements for ongoing upkeep and inspections by trained staff.

Checklist for Tests and Maintenance

Provides a checklist for performing inspections and maintenance tasks.

Troubleshooting Instructions

Malfunctions and Corresponding Remedies

Provides a guide to diagnose and fix common issues encountered with the door assistant.

DORMA Worldwide Contact Information
