DORMA PORTEO
WN 057472 45532 02/08
General safety instructions
1.
2.
3.
Intended application
PORTEO door assistants
PORTEO door assistant
PORTEO door assistant
Product-specific characteristics
PORTEO door assistants
Standards, laws, codes and regulations
PORTEO as low energy product according to German DIN 18650
(German industrial standard)
DORMA PORTEO door assistant “low energy”
.
.
Danger spots at closing edges
Required protection according to DIN 18650 for PORTEO door assistant "low energy"
DORMA PORTEO door assistant "low energy"
are only designed to open and close doors. Small children are not
allowed to play with the . Do not allow children to play with the
or rigidly mounted adjustment and/or control devices.
Keep the remote controls out of reach of children
are suitable for application at swing doors applied inside a building.
The latest versions of the common and country-specific standards, laws, codes and regulations
have to be observed.
According to the German industrial standard DIN 18650, the swing path of an automatic door
has to be protected amongst others by safety sensors. However, there are special requirements
for the application of a low-energy product.
The meets the requirements of a low-energy
application according to the standard by fulfilling the following requirements:
Reduced driving speeds (reduced dynamic forces at the door leaf and reduced dynamic
contact forces)
Force limitation (reduced static forces at the door leaf/reduced static contact forces)
Automatic doors might cause
hazards by crushing,
shearing, hitting and drawing-in
at the different closing edges.
The German industrial standard DIN 18650 has different requirements regarding the protection
of the above-mentioned danger spots.
For the application of the the following
requirements prevail:
An additional protection of the door system is not compulsory.
The application of safety sensors at the main closing edge and the opposite closing edge as
additional protection is optional and at the discretion of the person performing the
installation of the door system in accordance with the result of the individual risk assessment
(please also refer to "risk assessment", see page 6).
All people using a door are generally aware of the danger spot at the secondary closing edge
of every door (also at manually operated doors). This danger spot cannot be influenced by the
manufacturer of the operator and a protection of this closing edge often cannot be realised
due to its construction and technical function. A suitable clamping protection (e.g. rubber or
textile cover) is available in the specialised trade and is not part of the scope of delivery.
All in all: High safety standard of the application!
ü
ü
ü
ü
ü
ü
.
Secondary closing edge
Opposite closing edge
Main closing edge
GB 05
