DORMA PORTEO
WN 057472 45532 02/08
Extended commissioning
When it comes to deviations from the basic values of the original settings (see page 13), an extended
commissioning is required.
For example:
)
Approach in case of extended commissioning and learning cycle
Requirements
PORTEO door assistant
PORTEO door assistant
- projecting arm instead of slide channel
- a different door width (more than 1,000 mm
- a different door weight more than 60 kg)
You can stop and restart this procedure at any time by simply switching off the system.
- The has been installed.
- The door can easily be moved by hand.
The stored settings can be "overwritten" by a new commissioning procedure.
The "approach" describes the commissioning of the without any
accessory.
Accessories like for example electric strikes or sensors are adjusted following the successful
commissioning of the system.
Extended commissioning
Preparation 1
Close the door.
Preparation 2
ON
1 23 4
A BCD
OFF
1 23 4
A BCD
ON
OFF
Set DIP switch to position
-=
-=
(Set the switch to the correct position with
the aid of a small screwdriver.)
, the
has a different function, see page 23
.
Always set DIP switches , and to
position.
Select an arm version:
"A"
"ON" projecting arm
"OFF" slide channel
Following commissioning DIP switch "A"
"electric strike"
"B" "C" "D"
"OFF"
GB 16
