Dorma PORTEO - Requirements for Standard Commissioning

DORMA PORTEO
WN 057472 45532 02/08
Requirements for standard commissioning
Basic settings
basic settings
- lintel mounting
- with slide channel
- on the hinge side (pull side)
- door weight of up to 60 kg
- door width of up to 1,000 mm
standard commissioning
Deviations from basic values of original settings.
Door leaf width and admissible maximum weights
"extended commissioning"
The offer base values for these settings:
Most interior doors have a door width of less than 1,000 mm and a door weight of less than 60 kg.
As far as the structural conditions as well as the basic values of the lintel-mounted operator with
slide channel on the hinge side (pull side) correspond to the above-mentioned basic values, the
door closer can be commissioned with the aid of the .
page 16 to page 19.
In case the basic values are not identical with the basic settings, the deviant settings have to be
determined and adjusted.
The deviant settings are determined and readjusted during the ,
In case the basic values are not identical with the basic values of the , the
deviant settings have to be determined and adjusted during the .
original settings
extended commissioning
max. 1,000 mm
max.
60
KG
door leaf width in mm
600
700
800
900
1,000
1,100
max. door weights in kg
125
110
100
90
80
80
GB 13
