dormakaba ED100/ED250 Service Manual Chapter 8
. Door signage, full energy double swing doors
Fig. 8.5.1 One way traffic, approach side
50” ± 12”
DD0739-020
DD0739-020
50” ± 12”
Fig. 8.5.2 One way traffic, non-approach side
Fig. 8.5.4 Two way traffic, non-approach side
Fig. 8.5.6 Knowing act, non-approach side, one way
Fig. 8.5.3 Two way traffic, approach side
DD0739-020
DD0739-020
50” ± 12”
Fig. 8.5.5 Knowing act, approach side, one way
50” ± 12”
50” ± 12”
50” ± 12”
