dormakaba ED100/ED250 Service Manual Chapter 6
 User interface
. Overview
Fig. 6.1.1 Operator display and keypad
1 2 digit display
2 4 button keypad
•
.. Operator user interfaces
.  button keypad and  digit display.
•  button keypad; to input and adjust
door parameter values.
•  digit display; parameter values, error
and information codes.
.. button keypad functions
Fig. 6.2.1 4 button keypad and display
1 2 digit display
2 4 button keypad
.  button keypad and display
Right button
. Access parameter menu,
press button >  seconds.
. Edit selected parameter.
. Save changed value.
Left button
. Cancel parameter edit
process.
. Exit parameter menu,
press button <  s.
Both buttons
together
. Acknowledge errors,
press both buttons <  s.
. Reset, press both
buttons >  s.
Up button
. Scroll through parameters
and error messages.
. Increase parameter value.
Down button
. Scroll through parameters
and error messages.
. Reduce parameter value.
. Opening pulse, press
button <  s.
. Learning cycle, press
button >  s.
. Reset with factory setting,
press button >  s
(program switch Close
position).
. Identify operator
orientation for display.
12
1
2
