dormakaba ED100/ED250 Service Manual Chapters 4 and 5
 Recommended tools, tightening torque
1
5
Fig. 7.1.1 Recommended tools
5.1 Recommended tools
1 T-handle hex key,
5 mm
2 Hex keys, 2.5 mm,
3 mm, 6 mm
3 Screwdriver, flat blade
4 Door pressure gauge,
0 to 35 ft - lbf
5 Screwdriver, Phillips,
#2, #3
6 Torque wrench,
3 to 35 ft lb
6.1 5 mm hex key socket
7 Open end wrench,
13 mm
8 Screwdriver, flat
blade.,
M2 (1/16 to 3/32")
2
4
7
Fastener size ft lb N m
M . 
M  .
M  
M  
M  
5.2 Standard tightening torque
.. Standard tightening torque
3
8
1 Header
2 Program switch panel
3 Pull arm with track
4 Access hole for spring
tension
•
Fig. 4.2.1 ED100/ED250 header assembly
. Header assembly
1
2
3
4
6
6.1

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
