Dormakaba ED100 Service Manual

4
ED100/ED250 02-2018DL4614-050
dormakaba ED100/ED250 Service Manual Chapter 3
. Safety instructions
This document contains important information for
servicing ED100/ED250 swing door operators.
Review applicable information thoroughly prior to
operator troubleshooting and maintenance.
. Door signage requirements
Proper signs and labels shall be applied and maintained on
the door controlled by the ED100/ED250 swing door
operator per one of the following ANSI/BHMA standards:
• ANSI/BHMA A.-, Standard for power
operated doors, paragraph , signage.
• ANSI/BHMA A.-, Standard for power
assist and low energy power operated doors,
paragraph , signage.
. Safety warnings
WARNING
Hazard to mechanical processes by use of
control settings, elements, or procedures not
documented in this manual!
WARNING
Electric shock hazard!
• By use of control elements, settings, or
procedures not documented in this manual!
WARNING
Work on electrical equipment and 115 Vac wiring
must be performed only by qualified personnel!
 Safety information
WARNING
Hand pinch point and crushing hazards at door
closing edges!
WARNING
Crushing hazards at door closing edges!
WARNING
Hand pinch point and crushing hazards!
• Pull arm and track
• Push arm
Fig. 3.1 Door closing edges
1
2
3
1 Secondary closing edge
2 Opposing closing
edge
3 Main closing edge
Fig. 3.2 Pull arm and track
Fig. 3.3 Push arm

Dormakaba ED100 Specifications

General

Type	Universal
Purpose	Interior door
Product color	Gray
Hand orientation	-
Maximum door width	- mm
Maximum door weight	- kg
Placement supported	Overhead concealed door closer
Suitable for door type	Single-leaf door
Power source type	DC

Weight and Dimensions

Width	1422 mm
